The Y43 voltage output module is one of the Y series I/O modules for IOy series and ARMxy series products.This module features 4 output channels: AO1, AO2, AO3, and AO4, capable of outputting voltage signals of 0–5V and 0–10V to control field equipment.Each output channel is electrically isolated, and signals are transmitted with 16-bit resolution.
Power Supply
Operating Voltage
Internal Voltage
Power Consumption
2.6W
Analog Input
Channels
4CH
Output Type
0–5V / 0–10V
Resolution
16Bit
Accuracy
±0.1 % FSR @ 25 ℃
Conversion Time
20ms
Load Impedance
≥5kΩ
Certifications
EMC
IEC 61000-4-2 (ESD) Level 3
EMC
IEC 61000-4-4 (EFT) Level 3
EMC
IEC 61000-4-5 (Surge)Level 3
No.
Name
Model
Channel
Signal Type
1
4-Channel Analog Output Module
Y43
4
0-5V/0-10V
2
4-Channel Analog Output Module
Y46
4
-5-5V/-10-10V
Supply information
Manufacturer
BLIIoT — Beilai Technology Co., Ltd.
Model code
Y43
Full name
4CH 0~5V / 0~10V Voltage Analog Output Module
Category
Expansion Y boards
Supplied in Korea by
ACUSYS Co., Ltd. · Official BLIIoT distributor in Korea
