Industrial Cellular Router

The Industrial 4G Edge Router is not only an industrial router that provides wireless network access, but also features Modbus data acquisition, Modbus to MQTT protocol conversion, remote monitoring via cloud platform, Edge computing, programmable logic operations, etc.The R10A industrial router can provide wireless access network, and also can performs Modbus Master to poll meters over RS485/232 or LAN ports, then

Power Supply

Input voltage	9~36VDC
Input current	Normal: 130mA@12V. Maximum: 800mA@12V
Connection	3.5mm wiring terminal
Protection	Anti-reverse connection Protection

WAN

Qty	1
Interface Spec	RJ45 interface, 10M/100Mbps, adaptive MDI/MDIX
Protection	ESD ±30kV (contact), ±30kV (air) EFT 40A (5/50ns) Lightning 24A (8/20µs)

LAN (non-POE）

Qty	1
Interface Spec	RJ45 interface, 10M/100Mbps, adaptive MDI/MDIX
Protection	ESD ±30kV (contact), ±30kV (air) EFT 40A (5/50ns) Lightning 24A (8/20µs)

Serial Port

Qty	1
Type	1 Channel RS485 or RS232
Baud rate	1200，2400，4800，9600，14400，19200，38400，57600，115200，230400
Data Bit	5，6，7，8
Parity	None, Even, Odd
Stop Bit	1,2
Working mode	Transparent transmission, Modbus RTU to TCP, Modbus slave, Modbus master ( R10A support but R10 can’t)
Protection	ESD contact: 8KV Surge: 4KV (8/20us) ESD ±8kV (contact), ±15kV (air) EFT 4KV, 40A (5/50ns)

WIFI

Antenna Port qty	2
Antenna type	SMA hole type
Protocol	802.11a/b/g/n (mixed)
Mode	AP mode, client mode
Frequency	2.4G
Channel	Channel 1 - 13
Security	Open, WPA, WPA2
Encryption	AES, TKIP, TKIPAES
Connection number	16(Max)
Speed	300Mbps(Max)
Transmit Distance	Max. 20 meters in open space where there is no obstruction
SSID Broadcast Switch	Support

Cellular Network

Antenna Port Qty	1
Antenna Port Type	SMA hole type
4G(L-E)	GSM/EDGE：900,1800MHz WCDMA：B1,B5,B8 FDD：B1,B3,B5,B7,B8,B20 TDD：B38,B40,B41
4G(L- AU)	GSM/EDGE：850,900,1800MHz WCDMA：B1,B2,B5,B8 FDD：B1,B2,B3,B4,B5,B7,B8,B28 TDD：B40
4G(L-A)	WCDMA：B2,B4,B5 FDD：B2,B4,B12
4G(L-V)	FDD：B4,B13
4G(L-J)	WCDMA：B1,B3,B8,B18,B19,B26 FDD：B2,B4,B12 TDD: B41
4G(L-CE)	GSM/EDGE：900,1800MHz WCDMA：B1,B8 TD-SCDMA：B34,B39 FDD：B1,B3,B8 TDD：B38,B39,B40,B41

SIM

Qty	1
Interface Spec	Drawer interface, support 1.8V/3V SIM/UIM card (NANO)
Protection	Built-in 15KV ESD protection

GPS (optional)

Antenna qty	1
Antenna type	SMA hole type
Tracking Sensitivity	> -148 dBm
Horizontal Accuracy	2.5m
Protocol	NMEA-0183 V2.3

Indicator light

SYS	System running indicator (blinking for 2S and then off after normal operation)
4G	4G cellular operating status indicator ( when SIM registered successfully, this indicator always on )
WAN	WAN status indicator
LAN	LAN status indicator

System

CPU	MIPS CPU, main frequency 580Mhz
Storage	128Mbits SPI Flash
RAM	1024Mbits DDR2

Software

Network Protocol	PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, SSH2, DDNS
VPN	IPsec, OpenVPN, L2TP
Firewall	DMZ, DoS defense, IP packet, domain name and MAC address filtering, port mapping, access control
Remote Management	Supports web remote configuration
System Log	Support
Firmware Update	Supports serial port local TFTP and Web upgrade

Certificate

EMI	EN 55022: 2006/A1: 2007

Supply information

Manufacturer	BLIIoT — Beilai Technology Co., Ltd.
Model code	R10A
Full name	R10A | Industrial Cellular Router
Category	4G industrial routers
Supplied in Korea by	ACUSYS Co., Ltd. · Official BLIIoT distributor in Korea
